Family Name | Multi-Species |
Generic Type (Primary) | Fishing |
Manufacturer Country | USA |
Major Revision Year | 2016 |
Revision Status | New |
Competitor Code | BOA16FBF0000 |
Introduction Year | 2016 |
IsEmbargoed | No |
IsWIP | No |
IsPrelim | No |
IsCurrent | No |
Parent Company | Triton Boats, LLC |
Length (in/mm/ft/m) | 246 / 6200 / 20.5 / 6.2 |
Length (ft/ft) | 20 |
Length (ft/in) | 6 |
Beam (in/m) | 100 / 2.5 |
Transom Height (mm/in) | 635 / 25 |
Weight | Standard |
Fuel Capacity (gal/l) | 57 / 215.8 |
Number of Passengers | 4 |
Weight Capacity (lbs/kg) | 1810 / 821 |
Min Recommended Horsepower (bhp/kW) | 175 / 130.6 |
Max Recommended Horsepower (bhp/kW) | 250 / 186.6 |
Number Of Fresh Water Holding Tanks | 0 |
Total Fresh Water Tank Capacity (gal/l) | 0 / 0 |
Total Gray Water Tank Capacity (gal/l) | 0 / 0 |
Total Black Water Tank Capacity (gal/l) | 0 / 0 |
Number Of Water Ballast Tanks | 0 |
Total Water Ballast Tank Capacity (gal/l) | 0 / 0 |
Engine Brand Name | Optimax |
Engine Type | V6 |
Cylinders | 6 |
Engine Stroke | 2-Stroke |
Horsepower (bhp/kW) | 225 / 166 |
Cooling | Water (Open Loop) |
Valve Configuration | Reed Valve |
Bore (mm/in) | 92 / 3.5 |
Stroke (mm/in) | 76 / 3 |
Displacement (l) | 3 |
Starter | Electric |
Fuel Requirements | Regular |
Fuel Type | Gas / Oil Injected |
Turbocharged | No |
Supercharged | No |
Engine Model Code | Pro XS 225XL |
Engine Manufacturer | Mercury |
Engine Trim | Pro XS 225HP XL |
Full Throttle RPM Range Low | 5500 |
Full Throttle RPM Range High | 6000 |
Engine Dry Weight (lbs/Kg) | 505 / 229 |
Salt Water Capable | Yes |
Engine Alert System Type | Visual / Audible |
Emergency RPM Reduction | Yes |
Number Of Engines | 1 |
Engine Configuration | Outboard |
Fuel Injector | Yes |
Carburetor | No |
Carburetion Type | Direct Fuel Injection |
Tachometer | Standard |
Speedometer | Standard |
GPS Brand | Lowrance® |
Fuel Level Warning Type | Gauge |
Trim Indicator | Standard |
Depth Indicator | Standard |
Fish Finder | Standard |
Propulsion Type | Propeller |
Gear Ratio (s) | 1.75:1 |
Trim System Type | Power |
Twin Propeller | No |
Counter Rotating Capable | No |
Steering Assist System | Yes |
Outboard Steering Control | Remote |
Auto Pilot | No |
Hull Material | Fiberglass |
Boarding Ladder | Standard |
Bilge System Type | Automatic Siphon / Electric Pump |
Helm Seating Configuration | Chair |
Number Of Helm Seats | 1 |
Helm Roof Type | Open Top |
Pilot House Door | No |
Cockpit Flooring Type | Fiberglass |
Cockpit Table | No |
Number Of Cockpit Chairs | 3 |
Number Of Cockpit Sofas | 0 |
Number Of Open Bow Seats | 0 |
Number Of Sofas | 0 |
Number Of Chairs | 0 |
Number Of Convertible Beds | 0 |
Number Of Full Beds | 0 |
Number Of Single Beds | 0 |
Total Sleeping Capacity | 0 |
Number of Queen Beds | 0 |
Number Of Bridge Seats | 0 |
Number Of Bridge Chairs | 0 |
Fishing Rod Holders | Standard |
Number of Fishing Pedestal Chairs | 2 |
Total Baitwell Capacity (gal/l) | 10 / 42.4 |
Baitwell Pump | Yes |
Total Fishbox Capacity (gal/l) | 30 / 127.2 |
Fishbox Pump | Yes |
Trolling Motor Brand | Minn Kota® |
Trailer | Standard |
Walk-Through Windshield | Yes |
Ski / Wakeboard Storage | Standard |
