Family Name | SA |
Generic Type (Primary) | Ski / Wakeboard |
Manufacturer Country | USA |
Major Revision Year | 2015 |
Revision Status | New |
Competitor Code | BOA15SWK0000 |
Introduction Year | 2015 |
IsEmbargoed | No |
IsWIP | No |
IsPrelim | No |
IsCurrent | No |
Parent Company | Skier's Choice, Inc. |
Length (in/mm/ft/m) | 308 / 7800 / 25.67 / 7.8 |
Length (ft/ft) | 25 |
Length (ft/in) | 8 |
Beam (in/m) | 102 / 2.6 |
Draft (Drive Up) (in/mm) | 27 / 685.8 |
Draft (Drive Down) (in/mm) | 27 / 685.8 |
Number Of Pontoons | 0 |
Dry Weight (lbs/kg) | 5100 / 2313.4 |
Fuel Capacity (gal/l) | 72 / 272.5 |
Number of Passengers | 17 |
Weight Capacity (lbs/kg) | 2500 / 1134 |
Performance | Standard |
Number Of Fresh Water Holding Tanks | 0 |
Total Fresh Water Tank Capacity (gal/l) | 0 / 0 |
Total Gray Water Tank Capacity (gal/l) | 0 / 0 |
Total Black Water Tank Capacity (gal/l) | 0 / 0 |
Number Of Water Ballast Tanks | 3 |
Total Water Ballast Tank Capacity (gal/l) | 383.5 / 1449.6 |
Engine Brand Name | Raptor |
Engine Type | V8 |
Cylinders | 8 |
Engine Stroke | 4-Stroke |
Torque (Ft Lbs/Nm) | 575 / 779.6 |
Cooling | Water (Open Loop) |
Valves | 16 |
Valves Per Cylinder | 2 |
Valve Configuration | SOHC |
Bore (mm/in) | 102 / 4.02 |
Stroke (mm/in) | 95 / 3.74 |
Displacement (l) | 6.2 |
Compression Ratio | 9.8:1 |
Starter | Electric |
Fuel Requirements | Mid Grade |
Fuel Type | Gas |
Turbocharged | No |
Supercharged | Yes |
Engine Model Code | 575 Roush |
Engine Manufacturer | Indmar |
Engine Trim | Raptor 575 Roush |
Salt Water Capable | No |
Engine Alert System Type | Visual / Audible |
Emergency RPM Reduction | Yes |
Number Of Engines | 1 |
Engine Configuration | Inboard |
Fuel Injector | Yes |
Carburetor | No |
Carburetion Type | Fuel Injected |
Tachometer | Standard |
Speedometer | Standard |
GPS | Standard |
Fuel Level Warning Type | Gauge |
Depth Indicator | Standard |
Propulsion Type | Propeller |
Trim System | Standard |
Propeller | Standard |
Steering Assist System | Yes |
Outboard Steering Control | Remote |
Auto Pilot | No |
Hull Material | Fiberglass |
Hot Water | No |
Swim Platform | Standard |
Front Curtain | No |
Side Curtains | No |
Aft Curtain | No |
Aft Sunshade | No |
Camper Back | No |
Bow Cover | No |
Bridge Enclosure | No |
Bilge System Type | Automatic Siphon / Electric Pump |
Bilge Pump Alarm | Yes |
Engine Compartment Blowers | Standard |
Wake Control | Standard |
Helm Seating Configuration | Chair |
Number Of Helm Seats | 1 |
Helm Roof Type | Bimini Top |
Pilot House Door | No |
Cockpit Flooring Type | Carpeted |
Cockpit Table | Yes |
Number Of Cockpit Chairs | 0 |
Number Of Cockpit Sofas | 1 |
Number Of Open Bow Seats | 3 |
Number Of Sofas | 0 |
Number Of Chairs | 0 |
Number Of Convertible Beds | 0 |
Number Of Full Beds | 0 |
Number Of Single Beds | 0 |
Total Sleeping Capacity | 0 |
Number of Queen Beds | 0 |
Galley Table Configuration | No Galley Table |
Convection | No |
Number Of Bridge Seats | 0 |
Bridge Carpeting | No |
Bridge Table | No |
Number Of Bridge Chairs | 0 |
Number Of Bridge Sofas | 0 |
Sun Pad | Standard |
Full Head | No |
Number of Fishing Pedestal Chairs | 0 |
Total Baitwell Capacity (gal/l) | 0 / 0 |
Baitwell Pump | No |
Total Fishbox Capacity (gal/l) | 0 / 0 |
Fishbox Pump | No |
Trailer | Standard |
Walk-Through Windshield | Yes |
Brand Name | Polk |
Satellite | No |
Tow Pylon | Standard |
Wakeboard Tower | Standard |
Wakeboard Tower Rack | Standard |
Wakeboard Tower Speakers | Standard |
Ski / Wakeboard Storage | Standard |
