Family Name | LF |
Generic Type (Primary) | Fishing |
Manufacturer Country | USA |
Major Revision Year | 2015 |
Revision Status | New |
Competitor Code | BOA15FBD0000 |
Introduction Year | 2015 |
IsEmbargoed | No |
IsWIP | No |
IsPrelim | No |
IsCurrent | No |
Parent Company | Stingray® Boat Company |
Length (in/mm/ft/m) | 227 / 5800 / 18.92 / 5.8 |
Length (ft/ft) | 18 |
Length (ft/in) | 11 |
Beam (in/m) | 88 / 2.2 |
Bridge Clearance (in/m) | 45 / 1.1 |
Draft (Drive Up) (in/mm) | 18 / 457.2 |
Draft (Drive Down) (in/mm) | 29 / 736.6 |
Deadrise (deg) | 19 |
Number Of Pontoons | 0 |
Dry Weight (lbs/kg) | 2350 / 1066 |
Fuel Capacity (gal/l) | 21 / 79 |
Number of Passengers | 7 |
Weight Capacity (lbs/kg) | 1100 / 499 |
Min Recommended Horsepower (bhp/kW) | 135 / 100.7 |
Max Recommended Horsepower (bhp/kW) | 135 / 100.7 |
Number Of Fresh Water Holding Tanks | 1 |
Total Fresh Water Tank Capacity (gal/l) | 6 / 23 |
Total Gray Water Tank Capacity (gal/l) | 0 / 0 |
Total Black Water Tank Capacity (gal/l) | 0 / 0 |
Number Of Water Ballast Tanks | 0 |
Total Water Ballast Tank Capacity (gal/l) | 0 / 0 |
Engine Brand Name | MerCruiser® |
Engine Type | In-line |
Cylinders | 4 |
Engine Stroke | 4-Stroke |
Horsepower (bhp/kW) | 135 / 99.3 |
Cooling | Water (Open Loop) |
Valves | 8 |
Valves Per Cylinder | 2 |
Valve Configuration | OHV |
Bore (mm/in) | 101 / 4 |
Stroke (mm/in) | 91 / 3.6 |
Displacement (l) | 3 |
Compression Ratio | 9.3:1 |
Starter | Electric |
Fuel Requirements | Regular |
Fuel Type | Gas |
Turbocharged | No |
Supercharged | No |
Engine Manufacturer | Mercury |
Engine Trim | 3.0L MPI ECT Alpha® One |
Full Throttle RPM Range Low | 4400 |
Full Throttle RPM Range High | 4800 |
Salt Water Capable | Yes |
Engine Alert System Type | Visual / Audible |
Emergency RPM Reduction | Yes |
Number Of Engines | 1 |
Engine Configuration | Stern Drive |
Fuel Injector | Yes |
Carburetor | No |
Carburetion Type | Fuel Injected |
Tachometer | Standard |
Speedometer | Standard |
Fuel Level Warning Type | Gauge |
Trim Indicator | Standard |
Propulsion Type | Propeller |
Stern Drive Brand | Alpha |
Trim System Type | Power |
Twin Propeller | No |
Counter Rotating Capable | Yes |
Outboard Steering Control | Remote |
Auto Pilot | No |
Hull Material | Fiberglass |
Swim Platform | Standard |
Boarding Ladder | Standard |
Anchor | Standard |
Bilge System Type | Automatic Siphon / Electric Pump |
Engine Compartment Blowers | Standard |
Helm Seating Configuration | Chair |
Number Of Helm Seats | 1 |
Helm Roof Type | Open Top |
Pilot House Door | No |
Cockpit Flooring Type | Fiberglass |
Cockpit Table | No |
Number Of Cockpit Chairs | 1 |
Number Of Cockpit Sofas | 1 |
Number Of Open Bow Seats | 2 |
Number Of Sofas | 0 |
Number Of Chairs | 0 |
Number Of Convertible Beds | 0 |
Number Of Full Beds | 0 |
Number Of Single Beds | 0 |
Total Sleeping Capacity | 0 |
Number of Queen Beds | 0 |
Galley Table Configuration | No Galley Table |
Number Of Bridge Seats | 0 |
Bridge Carpeting | No |
Bridge Table | No |
Number Of Bridge Chairs | 0 |
Number Of Bridge Sofas | 0 |
Sun Pad | Standard |
Full Head | No |
Fishing Rod Holders | Standard |
Number of Fishing Pedestal Chairs | 2 |
Total Baitwell Capacity (gal/l) | 0 / 0 |
Baitwell Pump | No |
Total Fishbox Capacity (gal/l) | 5.5 / 21 |
Fishbox Pump | Yes |
Cockpit Heater | No |
Cabin Heater | No |
Bridge Heater | No |
Trailer | Standard |
Walk-Through Windshield | Yes |
Satellite | No |
Ski / Wakeboard Storage | Standard |
