2021 Four Winns HD Surf HD5

2021 Four Winns HD Surf HD5
$110,485
Body Style: Ski / Wakeboard
Insurance: Get a free quote
Build & Price View Floorplan

Boat Specifications

  • Identification
    Family Name HD
    Generic Type (Primary) Ski / Wakeboard
    Manufacturer Country USA
    Major Revision Year 2018
    Revision Status Carryover
    Competitor Code BOA21SWK0000
    Introduction Year 2018
    IsEmbargoed No
    IsWIP No
    IsPrelim No
    IsCurrent Yes
    Parent Company Four Winns, LLC
  • Technical Specifications
    Length (in/mm/ft/m) 292 / 7400 / 24.33 / 7.4
    Length (ft/ft) 24
    Length (ft/in) 4
    Beam (in/m) 101 / 2.6
    Bridge Clearance (in/m) 56 / 1.4
    Draft (Drive Up) (in/mm) 30 / 760
    Draft (Drive Down) (in/mm) 35 / 890
    Deadrise (deg) 20
    Number Of Pontoons 0
    Dry Weight (lbs/kg) 3760 / 1705
    Fuel Capacity (gal/l) 55 / 208
    Number of Passengers 13
    Weight Capacity (lbs/kg) 2000 / 907
    Min Recommended Horsepower (bhp/kW) 300 / 149.2
    Max Recommended Horsepower (bhp/kW) 350 / 223.9
    Number Of Fresh Water Holding Tanks 1
    Total Fresh Water Tank Capacity (gal/l) 12 / 45
    Number Of Water Ballast Tanks 1
  • Engine
    Engine Brand Name Penta
    Engine Type V8
    Cylinders 8
    Engine Stroke 4-Stroke
    Horsepower (bhp/kW) 300 / 224
    Horsepower RPM 5800
    Cooling Water (Open Loop)
    Valves 16
    Valves Per Cylinder 2
    Valve Configuration OHV
    Bore (mm/in) 96 / 3.8
    Stroke (mm/in) 92 / 3.62
    Displacement (l) 5.3
    Compression Ratio 11.0:1
    Starter Electric
    Fuel Requirements Regular
    Fuel Type Gas
    Turbocharged No
    Supercharged No
    Engine Model Code V8-300-C
    Engine Manufacturer Volvo Penta
    Engine Trim V8-300 DPS Forward Drive
    Engine Dry Weight (lbs/Kg) 991 / 450
    Salt Water Capable Yes
    Engine Alert System Type Visual / Audible
    Emergency RPM Reduction Yes
    Number Of Engines 1
    Engine Configuration Stern Drive
    Fuel Injector Yes
    Carburetor No
    Carburetion Type Fuel Injected
  • Instrumentation
    Tachometer Standard
    Speedometer Standard
    Fuel Level Warning Type Gauge
    Trim Indicator Standard
  • Drive Line
    Propulsion Type Propeller Forward Drive
    Stern Drive Brand DPS
    Trim System Type Power
    Twin Propeller Yes
    Counter Rotating Capable Yes
  • Steering
    Steering Assist System Yes
    Auto Pilot No
  • Exterior
    Hull Material Fiberglass
    Boarding Step Standard
    Swim Platform Standard
    Boarding Ladder Standard
    Front Curtain No
    Side Curtains No
    Aft Curtain No
    Aft Sunshade No
    Camper Back No
    Bow Cover No
    Bridge Enclosure No
  • Convenience
    Bilge System Type Automatic Siphon / Electric Pump
    Bilge Pump Alarm Yes
    Wake Control Standard
  • Topside / Cabin
    Helm Seating Configuration Chair
    Number Of Helm Seats 1
    Helm Roof Type Open Top
    Pilot House Door No
    Cockpit Flooring Type Fiberglass
    Number Of Cockpit Chairs 2
    Number Of Cockpit Sofas 1
    Number Of Open Bow Seats 5
    Number Of Sofas 0
    Number Of Chairs 0
    Number Of Convertible Beds 0
    Number Of Full Beds 0
    Number Of Single Beds 0
    Total Sleeping Capacity 0
    Number of Queen Beds 0
    Galley Table Configuration No Galley Table
    Convection No
    Number Of Bridge Seats 0
    Bridge Carpeting No
    Bridge Table No
    Number Of Bridge Chairs 0
    Number Of Bridge Sofas 0
    Sun Pad Standard
    Head Type Cassette
    Full Head No
    Head Location Topside
  • Fishing
    Number of Fishing Pedestal Chairs 0
    Total Baitwell Capacity (gal/l) 0 / 0
    Baitwell Pump No
    Total Fishbox Capacity (gal/l) 0 / 0
    Fishbox Pump No
  • Air Conditioning & Heater
    Cockpit Heater No
    Cabin Heater No
    Bridge Heater No
  • Towing & Hauling
    Trailer Standard
  • Glass
    Walk-Through Windshield Yes
  • Audio & Communication
    Satellite No
  • Ski / Wakeboard
    Tow Pylon Standard
  • Storage
    Ski / Wakeboard Storage Standard
