Family Name | Signature Series |
Generic Type (Primary) | Bowrider |
Manufacturer Country | USA |
Major Revision Year | 2016 |
Revision Status | Carryover |
Competitor Code | BOA17BRK0000 |
Introduction Year | 2016 |
IsEmbargoed | No |
IsWIP | No |
IsPrelim | No |
IsCurrent | No |
Parent Company | Four Winns, LLC |
Length (in/mm/ft/m) | 293 / 7400 / 24.42 / 7.4 |
Length (ft/ft) | 24 |
Length (ft/in) | 5 |
Beam (in/m) | 101 / 2.6 |
Draft (Drive Up) (in/mm) | 18 / 457.2 |
Draft (Drive Down) (in/mm) | 35 / 889 |
Deadrise (deg) | 20 |
Number Of Pontoons | 0 |
Dry Weight (lbs/kg) | 4860 / 2204 |
Fuel Capacity (gal/l) | 55 / 208 |
Number of Passengers | Yacht Certified |
Weight Capacity (lbs/kg) | 2000 / 907 |
Min Recommended Horsepower (bhp/kW) | 200 / 149.2 |
Max Recommended Horsepower (bhp/kW) | 300 / 223.9 |
Number Of Fresh Water Holding Tanks | 1 |
Total Fresh Water Tank Capacity (gal/l) | 12 / 45 |
Engine Brand Name | E-TEC |
Engine Type | V6 |
Cylinders | 6 |
Engine Stroke | 2-Stroke |
Horsepower (bhp/kW) | 200 / 149 |
Cooling | Water (Open Loop) |
Valves | 0 |
Valves Per Cylinder | 0 |
Valve Configuration | Reed Valve |
Bore (mm/in) | 98 / 3.85 |
Stroke (mm/in) | 76 / 3 |
Displacement (l) | 3.4 |
Starter | Electric |
Fuel Requirements | Regular |
Fuel Type | Gas / Oil Injected |
Turbocharged | No |
Supercharged | No |
Engine Model Code | E200XH |
Engine Manufacturer | Evinrude® |
Engine Trim | E200XH |
Full Throttle RPM Range Low | 5400 |
Full Throttle RPM Range High | 6000 |
Engine Dry Weight (lbs/Kg) | 558 / 253 |
Salt Water Capable | Yes |
Engine Alert System Type | Visual / Audible |
Emergency RPM Reduction | Yes |
Number Of Engines | 1 |
Engine Configuration | Outboard |
Fuel Injector | Yes |
Carburetor | No |
Carburetion Type | Direct Fuel Injection |
Tachometer | Standard |
Speedometer | Standard |
Fuel Level Warning Type | Gauge |
Trim Indicator | Standard |
Depth Indicator | Standard |
Water Temperature Gauge | Standard |
Air Temperature Gauge | Standard |
Propulsion Type | Propeller |
Gear Ratio (s) | 1.85:1 |
Trim System Type | Power |
Twin Propeller | No |
Counter Rotating Capable | No |
Steering Assist System | Yes |
Outboard Steering Control | Remote |
Auto Pilot | No |
Hull Material | Fiberglass |
Boarding Step | Standard |
Swim Platform | Standard |
Boarding Ladder | Standard |
Front Curtain | No |
Side Curtains | No |
Aft Curtain | No |
Aft Sunshade | No |
Camper Back | No |
Bow Cover | No |
Bridge Enclosure | No |
Bilge System Type | Automatic Siphon / Electric Pump |
Bilge Pump Alarm | Yes |
Helm Seating Configuration | Chair |
Number Of Helm Seats | 1 |
Helm Roof Type | Bimini Top |
Pilot House Door | No |
Cockpit Flooring Type | Carpeted |
Number Of Cockpit Chairs | 1 |
Number Of Cockpit Sofas | 2 |
Number Of Open Bow Seats | 3 |
Number Of Sofas | 0 |
Number Of Chairs | 0 |
Number Of Convertible Beds | 0 |
Number Of Full Beds | 0 |
Number Of Single Beds | 0 |
Total Sleeping Capacity | 0 |
Number of Queen Beds | 0 |
Galley Table Configuration | No Galley Table |
Convection | No |
Number Of Bridge Seats | 0 |
Bridge Carpeting | No |
Bridge Table | No |
Number Of Bridge Chairs | 0 |
Number Of Bridge Sofas | 0 |
Head Type | Cassette |
Full Head | No |
Head Location | Topside |
Number of Fishing Pedestal Chairs | 0 |
Total Baitwell Capacity (gal/l) | 0 / 0 |
Baitwell Pump | No |
Total Fishbox Capacity (gal/l) | 0 / 0 |
Fishbox Pump | No |
Cockpit Heater | No |
Cabin Heater | No |
Bridge Heater | No |
Trailer | Standard |
Walk-Through Windshield | Yes |
Satellite | No |
Ski / Wakeboard Storage | Standard |
