Family Name | Fish |
Generic Type (Primary) | Center Console |
Manufacturer Country | USA |
Major Revision Year | 2015 |
Revision Status | New |
Competitor Code | BOA15CCE0000 |
Introduction Year | 2015 |
IsEmbargoed | No |
IsWIP | No |
IsPrelim | No |
IsCurrent | No |
Parent Company | Brunswick Corporation |
Length (in/mm/ft/m) | 216 / 5500 / 18 / 5.5 |
Length (ft/ft) | 18 |
Length (ft/in) | 0 |
Beam (in/m) | 86 / 2.2 |
Deadrise (deg) | 3.5 |
Transom Height (mm/in) | 508 / 20 |
Dry Weight (lbs/kg) | 970 / 440 |
Fuel Capacity (gal/l) | 19 / 71.9 |
Number of Passengers | 7 |
Weight Capacity (lbs/kg) | 1578 / 716 |
Min Recommended Horsepower (bhp/kW) | 25 / 18.7 |
Max Recommended Horsepower (bhp/kW) | 115 / 85.8 |
Number Of Fresh Water Holding Tanks | 0 |
Total Fresh Water Tank Capacity (gal/l) | 0 / 0 |
Total Gray Water Tank Capacity (gal/l) | 0 / 0 |
Total Black Water Tank Capacity (gal/l) | 0 / 0 |
Number Of Water Ballast Tanks | 0 |
Total Water Ballast Tank Capacity (gal/l) | 0 / 0 |
Engine Brand Name | Fourstroke |
Engine Type | In-line |
Cylinders | 3 |
Engine Stroke | 4-Stroke |
Horsepower (bhp/kW) | 25 / 18.6 |
Cooling | Water (Open Loop) |
Valves | 6 |
Valves Per Cylinder | 2 |
Valve Configuration | SOHC |
Bore (mm/in) | 61 / 2.4 |
Stroke (mm/in) | 60 / 2.36 |
Displacement (l) | 0.53 |
Starter | Electric |
Fuel Requirements | Regular |
Fuel Type | Gas |
Turbocharged | No |
Supercharged | No |
Engine Model Code | 25ELPT |
Engine Manufacturer | Mercury |
Engine Trim | 25HP ELPT |
Full Throttle RPM Range Low | 5000 |
Full Throttle RPM Range High | 6000 |
Engine Dry Weight (lbs/Kg) | 157 / 71 |
Salt Water Capable | Yes |
Engine Alert System Type | Visual |
Emergency RPM Reduction | Yes |
Number Of Engines | 1 |
Engine Configuration | Outboard |
Fuel Injector | Yes |
Carburetor | No |
Carburetion Type | Fuel Injected |
Tachometer | Standard |
Speedometer | Standard |
Fuel Level Warning Type | Gauge |
Trim Indicator | Standard |
Propulsion Type | Propeller |
Gear Ratio (s) | 1.92:1 |
Trim System Type | Power |
Twin Propeller | No |
Counter Rotating Capable | No |
Outboard Steering Control | Remote |
Auto Pilot | No |
Hull Material | Aluminum |
Bilge System Type | Automatic Siphon |
Helm Seating Configuration | Bench |
Number Of Helm Seats | 2 |
Helm Roof Type | Open Top |
Pilot House Door | No |
Cockpit Flooring Type | Aluminum |
Cockpit Table | No |
Number Of Cockpit Chairs | 1 |
Number Of Cockpit Sofas | 0 |
Number Of Open Bow Seats | 2 |
Number Of Sofas | 0 |
Number Of Chairs | 0 |
Number Of Convertible Beds | 0 |
Number Of Full Beds | 0 |
Number Of Single Beds | 0 |
Total Sleeping Capacity | 0 |
Number of Queen Beds | 0 |
Galley Table Configuration | No Galley Table |
Convection | No |
Number Of Bridge Seats | 0 |
Bridge Carpeting | No |
Bridge Table | No |
Number Of Bridge Chairs | 0 |
Number Of Bridge Sofas | 0 |
Full Head | No |
Fishing Rod Holders | Standard |
Number of Fishing Pedestal Chairs | 1 |
Total Fishbox Capacity (gal/l) | 16 / 67.8 |
Fishbox Pump | Yes |
Poling Platform | Standard |
Cockpit Heater | No |
Cabin Heater | No |
Bridge Heater | No |
Trailer | Standard |
Walk-Through Windshield | No |
