Family Name | Xtreme |
Generic Type (Primary) | Ski / Wakeboard |
Manufacturer Country | USA |
Major Revision Year | 2014 |
Revision Status | New |
Competitor Code | BOA14SWK0000 |
Introduction Year | 2014 |
IsEmbargoed | No |
IsWIP | No |
IsPrelim | No |
IsCurrent | No |
Parent Company | Chaparral Boats, Inc. |
Length (in/mm/ft/m) | 340 / 8600 / 28.33 / 8.6 |
Length (ft/ft) | 28 |
Length (ft/in) | 4 |
Beam (in/m) | 108 / 2.7 |
Bridge Clearance (in/m) | 88 / 2.2 |
Draft (Drive Up) (in/mm) | 26 / 660.4 |
Draft (Drive Down) (in/mm) | 39 / 990.6 |
Deadrise (deg) | 22 |
Dry Weight (lbs/kg) | 6800 / 3084 |
Fuel Capacity (gal/l) | 111 / 420 |
Number of Passengers | Yacht Certified |
Min Recommended Horsepower (bhp/kW) | 320 / 238.8 |
Max Recommended Horsepower (bhp/kW) | 430 / 321 |
Number Of Fresh Water Holding Tanks | 1 |
Total Fresh Water Tank Capacity (gal/l) | 22 / 83 |
Total Gray Water Tank Capacity (gal/l) | 3.8 / 14 |
Number Of Water Ballast Tanks | 0 |
Total Water Ballast Tank Capacity (gal/l) | 0 / 0 |
Engine Brand Name | MerCruiser® |
Engine Type | V8 |
Cylinders | 8 |
Engine Stroke | 4-Stroke |
Horsepower (bhp/kW) | 380 / 283 |
Cooling | Liquid |
Valves | 16 |
Valves Per Cylinder | 2 |
Valve Configuration | OHV |
Bore (mm/in) | 113.5 / 4.47 |
Stroke (mm/in) | 101.6 / 4 |
Displacement (l) | 8.2 |
Compression Ratio | 8.75:1 |
Starter | Electric |
Fuel Requirements | Regular |
Fuel Type | Gas |
Turbocharged | No |
Supercharged | No |
Engine Manufacturer | Mercury |
Engine Trim | 8.2L MAG ECT Bravo Three X® |
Full Throttle RPM Range Low | 4400 |
Full Throttle RPM Range High | 4800 |
Salt Water Capable | Yes |
Engine Alert System Type | Visual / Audible |
Emergency RPM Reduction | Yes |
Number Of Engines | 1 |
Engine Configuration | Stern Drive |
Fuel Injector | Yes |
Carburetor | No |
Carburetion Type | Fuel Injected |
Tachometer | Standard |
Speedometer | Standard |
Fuel Level Warning Type | Gauge |
Compass | Standard |
Depth Indicator | Standard |
Propulsion Type | Propeller |
Stern Drive Brand | Bravo Three X® |
Trim System Type | Power |
Twin Propeller | Yes |
Counter Rotating Capable | Yes |
Steering Assist System | Yes |
Outboard Steering Control | Remote |
Auto Pilot | No |
Hull Material | Fiberglass |
Boarding Step | Standard |
Exterior Shower | Standard |
Swim Platform | Standard |
Boarding Ladder | Standard |
Radar Arch | Standard |
Front Curtain | Yes |
Side Curtains | No |
Aft Curtain | No |
Aft Sunshade | Yes |
Camper Back | No |
Bow Cover | No |
Bridge Enclosure | No |
Anchor | Standard |
Bilge System Type | Automatic Siphon / Electric Pump |
Bilge Pump Alarm | Yes |
Engine Compartment Blowers | Standard |
Wake Control | Standard |
Helm Seating Configuration | Chair |
Number Of Helm Seats | 1 |
Helm Roof Type | Bimini Top |
Pilot House Door | No |
Cockpit Flooring Type | Fiberglass |
Cockpit Table | Yes |
Number Of Cockpit Chairs | 1 |
Number Of Cockpit Sofas | 1 |
Cockpit Wet Bar | Standard |
Number Of Open Bow Seats | 5 |
Number Of Sofas | 0 |
Number Of Chairs | 0 |
Number Of Convertible Beds | 0 |
Number Of Full Beds | 0 |
Number Of Single Beds | 0 |
Total Sleeping Capacity | 0 |
Number of Queen Beds | 0 |
Galley Table Configuration | No Galley Table |
Convection | No |
Number Of Bridge Seats | 0 |
Number Of Bridge Chairs | 0 |
Number Of Bridge Sofas | 0 |
Sun Pad | Standard |
Head Type | Cassette |
Full Head | Yes |
Head Location | Topside |
Number of Fishing Pedestal Chairs | 0 |
Total Baitwell Capacity (gal/l) | 0 / 0 |
Baitwell Pump | No |
Total Fishbox Capacity (gal/l) | 0 / 0 |
Fishbox Pump | No |
Walk-Through Windshield | Yes |
Satellite | Yes |
CD Player | Standard |
Tow Pylon | Standard |
Wakeboard Tower | Standard |
Wakeboard Tower Rack | Standard |
Wakeboard Tower Speakers | Standard |
Ski / Wakeboard Storage | Standard |
